Product Information
- Exterior Gauge
- 26, 24, 22
- Interior Gauge
- 26, 24, 22
- Substrate
- 55% Al-Zn Alloy Coated Steel with Acrylic Coating
- Metallic Coated Steel
- Stainless Steel
- Minimum Panel Length
- 12′-0″
- Maximum Panel Length
- 53′-0″
- Core
- Continuously poured-in-place, polyisocyanurate, insulating foam
Product Options
- Thickness
- 2.5″, 3″, 4″, 5″, 6″
- Exterior Finish
- 70% PVDF – Standard Gloss
- Siliconized Polyester
- Interior Finish
- Polyester (USDA White)
- Siliconized Polyester (USDA White)
- 70% PVDF – Standard Gloss
- Plastisol
- Stainless
Product Options
- Exterior texture
- Smooth
- Interior texture
- Smooth
- Stucco Embossed
- Choice of 16 stock colors
- Applications
- Roofs
- Open framing
- Minimum slope ½:12
